Nominal
pressure |
700KN |
Outer
width of the machine |
2700mm |
Slider
stroke |
160mm |
Lateral depth
of the machine |
1550mm |
Numerical control axis
number |
4+1(+2) |
Total machine
height |
2400mm |
Main
motor power |
5.5KW |
Workbench
length |
2500mm |
Running speed
of slider |
Fast
|
250mm/s |
Column
spacing |
2000mm |
Work
|
15mm/s |
Open height |
430mm |
Return trip
Retum trip |
160mm/s |
Throat depth |
300mm |
Backshift X-axis
Real gear X shaft |
Trip
|
500mm |
Note:
Y1 and Y2 axis - control slider up and down movement
X axis - control backward and rearward movement
R axis - control backward and downward movement
V axis - mechanical deflection compensation (optional)
Note:
Y1, Y2 axis -control sliding block up and down motion
X axis - back and forth movement of control rear qear
R axis - control up and down movement of post-gear
V axis -mechanical defect compensation( Optional) |
| Maximum running speed |
600mm/s |
| Repeatable positioning accuracy |
0.02mm |
Backshift R shaft
Real gear R shaft |
Trip
|
160mmmm |
| Maximum running speed |
300mm/s |
| Repeatable positioning accuracy |
0.02mm |
