Nominal
pressure | 400KN | Outer
width of the machine | 1700mm |
Slider
stroke | 160mm | Lateral depth
of the machine | 1400mm |
Numerical control axis
number | 4(+2) | Total machine
height | 2300mm |
Main
motor power | 5.5KW | Workbench
length | 1600mm |
Running speed
of slider | Fast
| 250mm/s | Column
spacing | 1210mm |
Work
| 15mm/s | Open height | 430mm |
Return trip
Retum trip | 180mm/s | Throat depth | 300mm |
Backshift X-axis
Real gear X shaft | Trip
| 500mm | Note:
Y1 and Y2 axis - control slider up and down movement
X axis - control backward and rearward movement
R axis - control backward and downward movement
V axis - mechanical deflection compensation (optional)
Note:
Y1, Y2 axis -control sliding block up and down motion
X axis - back and forth movement of control rear qear
R axis - control up and down movement of post-gear
V axis -mechanical defect compensation( Optional) |
| Maximum running speed | 600mm/s |
| Repeatable positioning accuracy | 0.02mm |
Backshift R shaft
Real gear R shaft | Trip
| 160mm |
| Maximum running speed | 300mm/s |
| Repeatable positioning accuracy | 0.02mm |
